THCR-25

Name: THCR-25
Brand: PROASTER
SKU: THCR-25

The moment a roastery becomes a production facility. A high-capacity commercial coffee roaster, with batches up to 30 kg.

Request a Quote

3-phase 4-wire 380V 60 Hz

LPG (low-pressure) 65,360 kcal/h

10~30 kg/batch

8~20 mins

Features

Semi-Hot-Air Roasting
A roasting method that combines stable radiant heat with hot air for rich flavor, delivering more uniform heat transfer than direct-flame drums.
Separated Cooler / Blender
The cooler is separated from the main body and doubles as a blending chamber — a two-in-one design that improves throughput.
Maximum Thermal Efficiency
A high-efficiency drum design that lets you complete a roast in about 10 minutes while preserving rich body and aroma.
Precise Damper Control
Damper adjustment lets you fine-tune exhaust flow, giving you delicate control over flavor and aroma.
Rapid Cooling System
A dedicated high-power blower cools the beans quickly, locking in flavor and aroma.
Flame Failure / Power-Loss Safety
If power fails or the exhaust blower stops, the gas valve will not open.
Overheating Protection
Gas is shut off automatically when the operating temperature is exceeded.

Dimensions W×L×H (mm): 1288 x 2643 x 2830mm (Main body)2000 x 5420 x 2830mm (Installed, incl. vacuum stone sorter & afterburner)
Power: 3-phase 4-wire 380V 60Hz
Batch Capacity: 10kg~27kg / batch (MAX 30kg)
Roast Time: 8~20 MINS
Power Consumption: 6kw/hr
Gas Pressure: Low-pressure LPG [2.8~-0.5] kpa | LNG [2.0+0.5/-1.0] kpa
Gas Consumption: LPG 5.6kg/hr | LNG 65,360kcal/hr
Weight: 760kg(Main body), 110kg(Cooler), 100kg(Cyclone)
