THCR-03

Name: THCR-03
Brand: PROASTER
SKU: THCR-03

In-store roasting and wholesale production in one. A commercial roaster that balances quality and output, with batches up to 5 kg.

Request a Quote

1-phase 220V 60 Hz

LPG (low-pressure) 17,000 kcal/h

2~5 kg/batch

5~20 mins

Features

Semi-Hot-Air Roasting
A roasting method that combines stable radiant heat with hot air for rich flavor, delivering more uniform heat transfer than direct-flame drums.
Maximum Thermal Efficiency
A high-efficiency drum design that lets you complete a roast in about 10 minutes while preserving rich body and aroma.
Precise Damper Control
Damper adjustment lets you fine-tune exhaust flow, giving you delicate control over flavor and aroma.
Rapid Cooling System
A dedicated high-power blower cools the beans quickly, locking in flavor and aroma.
Flame Failure / Power-Loss Safety
If power fails or the exhaust blower stops, the gas valve will not open.
Overheating Protection
Gas is shut off automatically when the operating temperature is exceeded.

Dimensions W×L×H (mm): 674 x 1659 x 1591 mm (Main body)855 x 1890 x 1591 mm (Installed)
Power: 1-phase 220V 60Hz
Batch Capacity: 2kg~4kg / batch (MAX 5kg)
Roast Time: 5~20 MINS
Power Consumption: 1kw/hr
Gas Pressure: Low-pressure LPG [2.8~-0.5] kpa | LNG [2.0~0.5/-1.0] kpa
Gas Consumption: LPG 1.1kg/hr | LNG 17,000kcal/hr
Weight: 300kg(Main body), 30kg(Cyclone)
